Product Details :

• Service Providers: GSM operators can increase their revenue by replacing existing analog lines with SIMADO GFX11 and offer customers to switch to their GSM network.
• Offices: SIMADO GFX11 helps in reducing company's telecommunication cost up to 30%. By connecting SIMADO to the existing PBX, all calls made to the mobile phones will be routed through SIMADO GFX11.
• Payphones (PCO): SIMADO GFX11 can be connected to a payphone thus allowing it to be used anywhere within GSM coverage area. It provides Battery Polarity Reversal on its FXS port to activate the payphone metering mechanism.
• Emergency Applications: SIMADO GFX11 supports programming of a help-line or emergency number as a Hotline number. Hence, during any emergency situation the caller can dial the emergency number just by lifting the handset. SIMADO has important usage at places like National Highways, Hospitals, Railways, Airports, etc., which are prone to high-emergency occurrence.

Technical Specification :

SIMADO GFX11

• GSM (2G) FCT for Voice Applications Mobile Port

GSM/4G SIM Cards

• 1

Frequency Bands

• Quad-band GSM850, EGSM900, DCS1800, PCS1900, UMTS850, UMTS900, UMTS1900, UMTS2100, PCS1900 Tri-band WCDMA 850/1900/2100 MHz or Tri-band WCDMA 900/1900/2100 MHz

SIM Interface

• 1.8, 3V SIM Interface

Compliance

• ETSI GSM Phase2/2+

FXS Port

Connector

• RJ11

Dialling and Reception

• Pulse and DTMF Dialling

CLIP

• DTMF and FSK CLI Presentation

Answering and Disconnect Signalling

• Polarity Reversal for Call Connect/Disconnect Signalling

Power Supply

Input

• External Power Adaptor 100-240 VAC, 47-63Hz Output: 12VDC@1.25A

Power Consumption

• 5W (Typical)

Other

Dimensions (W x H x D)

• 133.5 x 198 x 44.6 mm

Mounting Options

• Wall Mount and table Top

Operating Temperature

• 0°C to +45°C (34°F to +133°F)
